Types of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes are able to transport loads between any areas within the boom's arc of rotation. Light duty units are used within factories and warehouses for loads weighing as much as 5 tons. The website BestJibCranes.com showcases the major jib crane types as being either free-standing, wall-mounted or mast mounted.
Free Standing
The free-standing jib crane models do not require any support from the building structure and could stand by themselves. The horizontal boom in this specific situation is connected to a pivoting vertical column that is anchored firmly to the building floor. This type of jib crane is able to rotate a full 360 degrees and needs a foundation made of either steel or concrete.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom which are connected to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the advantage of not needing the massive foundation required for free-standing units.
Wall Mounted
Wall mounted jib cranes are attached to the wall of the building instead of supporting a normal vertical column. These cranes provide a horizontal boom. These machinery provide up to 200 degrees of rotation and are great in areas where the full 360 degree rotation is not required.
There are two model varieties, depending on how the boom is supported. One of the kinds uses a tie rod which is connected from above the wall to the boom. The other type supports the boom from below by using a cantilever brace that is also connected to the wall.
