Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction equipment. They manufacture machines like manlifts, boom lifts and aerial lifts. These types of machinery are designed to facilitate access to hard to reach areas, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves just in one direction and contains handholds or platforms or steps that are connected to the unit in order to move workers from each floor.
TB85
The TB85 by Terex offers a maximum working height of 91 feet. In addition, the maximum height of the platform reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model provides a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is around 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height reaches 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
